L610Q400 系列_2
瀏覽量：913 上傳更新：2020-07-13
L610Q400 系列_2

These low-power microcontrollers with segment LCD driver integrates a boost circuit for driving an LCD. The lineup ranges from 55 to 185 segments. Additional features include built-in program memory (6KB-64KB) and RAM (192B-2KB), 2 types of serial communication interfaces (SSIO, UART) or 3 types of serial communication ports (I2C, SSIO, UART), 16bit/24bit RC oscillation A/D converter, 12bit successive approximation A/D converter, melody, buzzer, timer, and general-purpose port, making them ideal for compact, LCD-equipped devices.


Part No.

Operating condition

ROM/RAM

Function/Feature

Package

In
chip

Operating
voltage
(V)

Operating*1
frequency

Current*3
con
-sump
-tion
(Typ.
@HALT)

Operating
temper
-ature
(°C)

ROM
capacity
(Byte)

RAM
capacity
(Byte)

W
D
T

ADC
(Method)

Serial port

LCD
driver

I2C

S
S
I
O*7

U
A
R
T*8

  • ML610401
    ML610401P



1.25
to
3.6

500
kHz
32.768
kHz

0.9
μA

–20 to +70
/–40 to +85

Mask
6K*9

192

1

2(RC oscillation)

–

–

1

Max.
55dot11seg
×
5com

TQFP
64

OK

  • ML610402
    ML610402P



1.25
to
3.6

500
kHz
32.768
kHz

0.9
μA

–20 to +70
/–40 to +85

Mask
6K*9

192

1

2(RC oscillation)

–

–

1

Max.
75dot15seg
×
5com

TQFP
64

OK

  • ML610403
    ML610403P



1.25
to
3.6

500
kHz
32.768
kHz

0.9
μA

–20 to +70
/–40 to +85

Mask
6K*9

192

1

2(RC oscillation)

–

–

1

Max.
95dot19seg
×
5com

TQFP
64

OK

NEW

  • ML610404
    ML610404P



1.25
to
3.6

2
MHz
32.768
kHz

0.9
μA

–20 to +70
/–40 to +85

Mask
8K*9

256

1

2(RC oscillation)

–

2

1

Max.
105dot21seg
×
5com

TQFP
80

OK

NEW

  • ML610405
    ML610405P



1.25
to
3.6

2
MHz
32.768
kHz

0.9
μA

–20 to +70
/–40 to +85

Mask
8K*9

256

1

2(RC oscillation)

–

2

1

Max.
125dot25seg
×
5com

TQFP
80

OK

NEW

  • ML610406
    ML610406P



1.25
to
3.6

2
MHz
32.768
kHz

0.9
μA

–20 to +70
/–40 to +85

Mask
8K*9

256

1

2(RC oscillation)

–

2

1

Max.
145dot29seg
×
5com

TQFP
80

OK

  • ML610407
    ML610407P



1.25
to
3.6

2
MHz
32.768
kHz

0.9
μA

–20 to +70
/–40 to +85

Mask
16K*10

1K

1

2(RC oscillation)

–

2

1

Max.
145dot29seg
×
5com

TQFP
100

OK

  • ML610408
    ML610408P



1.25
to
3.6

2
MHz
32.768
kHz

0.9
μA

–20 to +70
/–40 to +85

Mask
16K*10

1K

1

2(RC oscillation)

–

2

1

Max.
165dot33seg
×
5com

TQFP
100

OK

  • ML610409
    ML610409P


1.25
to
3.6

2
MHz
32.768
kHz

0.9
μA

–20 to +70
/–40 to +85

Mask
16K*10

1K

1

2(RC oscillation)

–

2

1

Max.
185dot37seg
×
5com

TQFP
100

OK

  • ML610Q407
    ML610Q407P


1.25
to
3.6

2
MHz
32.768
kHz

0.9
μA

–20 to +70
/–40 to +85

Flash
16K*10

1K

1

2(RC oscillation)

–

2

1

Max.
145dot29seg
×
5com

TQFP
100

OK

  • ML610Q408
    ML610Q408P


1.25
to
3.6

2
MHz
32.768
kHz

0.9
μA

–20 to +70
/–40 to +85

Flash
16K*10

1K

1

2(RC oscillation)

–

2

1

Max.
165dot33seg
×
5com

TQFP
100

OK

  • ML610Q409
    ML610Q409P


1.25
to
3.6

2
MHz
32.768
kHz

0.9
μA

–20 to +70
/–40 to +85

Flash
16K*10

1K

1

2(RC oscillation)

–

2

1

Max.
185dot37seg
×
5com

TQFP
100

OK

  • ML610Q411

  • ML610Q411P


1.1
to
3.6

500
kHz
32.768
kHz

0.5
μA

–20 to +70
/–40 to +85

Flash
16K*10

1K

1

2(RC oscillation)
2(Succes
-sive)

1*5

1

1

Max.
144dot36seg
×
4com

TQFP
120

OK

  • ML610Q412

  • ML610Q412P


1.1
to
3.6

500
kHz
32.768
kHz

0.5
μA

–20 to +70
/–40 to +85

Flash
16K*10

1K

1

2(RC oscillation)
2(Succes
-sive)

1*5

1

1

Max.
176dot44seg
×
4com

TQFP
120

OK

  • ML610Q415


1.1
to
3.6

500
kHz

5.5
μA

–20 to +70

Flash
16K*10

1K

1

2(RC oscillation)
2(Succes
-sive)

1*5

1

1

Max.
144dot36seg
×
4com

TQFP
120

OK

NEW

  • ML610Q419(P)

  • ML610Q419(P)C

1.1
to
3.6

4.096
MHz
500
kHz
32.768
kHz

0.9
μA

–20 to +70
/–40 to +85

Flash
64K*10
+4K(Self-rewritable area)

2K

1

2(RC oscillation)
4(Sequential）

1*5

2

1

Max.
192dot48seg
×
4com(Q419/
419P)
Max.
160dot40seg
×
4com
(Q419C/
419PC)

TQFP
100

OK

NEW

  • ML610471

  • ML610471P


1.25
to
3.6

500
kHz
32.768
kHz

0.8
μA

–20 to +70
/–40 to +85

Mask
8K*9

512

1

1(RC oscillation)

–

-

1

Max.
55dot11seg
×
5com

TQFP
48/64

OK

NEW

  • ML610Q471

  • ML610Q471P


1.25
to
3.6

500
kHz
32.768
kHz

0.8
μA

–20 to +70
/–40 to +85

Flash
8K*9

512

1

1(RC oscillation)

–

-

1

Max.
55dot11seg
×
5com

TQFP
48/64

OK

NEW

  • ML610472

  • ML610472P



1.25
to
3.6

500
kHz
32.768
kHz

0.8
μA

–20 to +70
/–40 to +85

Mask
8K*9

512

1

1(RC oscillation)

–

-

1

Max.
75dot15seg
×
5com

TQFP
48/64

OK

NEW

  • ML610Q472

  • ML610Q472P


1.25
to
3.6

500
kHz
32.768
kHz

0.8
μA

–20 to +70
/–40 to +85

Flash
8K*9

512

1

1(RC oscillation)

–

-

1

Max.
75dot15seg
×
5com

TQFP
48/64

OK

NEW

  • ML610473

  • ML610473P

1.25
to
3.6

500
kHz
32.768
kHz

0.8
μA

–20 to +70
/–40 to +85

Mask
8K*9

512

1

1(RC oscillation)

–

-

1

Max.
95dot19seg
×
5com

TQFP
48/64

OK

NEW

  • ML610Q473

  • ML610Q473P


1.25
to
3.6

500
kHz
32.768
kHz

0.8
μA

–20 to +70
/–40 to +85

Flash
8K*9

512

1

1(RC oscillation)

–

-

1

Max.
95dot19seg
×
5com

TQFP
48/64

OK

under development

  • ML610477

  • ML610477P

1.25
to
3.6

2MHz
500
kHz
32.768
kHz

0.51
μA
(MASK T.B.D)

–20 to +70
/–40 to +85

Mask
24K*9

2K

1

1(RC oscillation)

–

-

1

Max.
135dot27seg
×
5com

TQFP
80

OK

NEW

  • ML610Q477

  • ML610Q477P

1.25
to
3.6

2MHz
500
kHz
32.768
kHz

0.8
μA

–20 to +70
/–40 to +85

Flash
24K*9

2K

1

1(RC oscillation)

–

-

1

Max.
135dot27seg
×
5com

TQFP
80

OK

under development

  • ML610478

  • ML610478P

1.25
to
3.6

2MHz
500
kHz
32.768
kHz

0.51
μA
(MASK T.B.D)

–20 to +70
/–40 to +85

Mask
24K*9

2K

1

1(RC oscillation)

–

-

1

Max.
155dot31seg
×
5com

TQFP
80

OK

NEW

  • ML610Q478

  • ML610Q478P

1.25
to
3.6

2MHz
500
kHz
32.768
kHz

0.8
μA

–20 to +70
/–40 to +85

Flash
24K*9

2K

1

1(RC oscillation)

–

-

1

Max.
155dot31seg
×
5com

TQFP
80

OK

under development

  • ML610479

  • ML610479P

1.25
to
3.6

2MHz
500
kHz
32.768
kHz

0.51
μA
(MASK T.B.D)

–20 to +70
/–40 to +85

Mask
24K*9

2K

1

1(RC oscillation)

–

-

1

Max.
175dot35seg
×
5com

TQFP
80

OK

NEW

  • ML610Q479

  • ML610Q479P

1.25
to
3.6

2MHz
500
kHz
32.768
kHz

0.8
μA

–20 to +70
/–40 to +85

Flash
24K*9

2K

1

1(RC oscillation)

–

-

1

Max.
175dot35seg
×
5com

TQFP
80

OK

*By mask option, ON or OFF of oscillation stop detection reset function for ML610401/P, ML610402/P, ML610403/P, ML610404/P, ML610405/P, ML610406/P, ML610407/P, ML610408/P, and ML610409/P is selectable.
*No oscillation stop detection reset function for ML610Q407A/PA, ML610Q408A/PA, ML610Q409A/PA, ML610Q411A/PA, and ML610Q412A/PA.
*1: 4MHz supports internal PLL, ceramic, crystal, or RC oscillation; 2MHz, 1MHz, or 500kHz supports RC oscillation; 32.768kHz supports crystal oscillation; 32kHz supports RC oscillation
*3: Current consumption during Suspend (HALT) mode at low-speed 32kHz oscillation
*5: Master function only, supports both Fast Mode (400kbps) and Standard Mode (100kbps)
*7: No compatible chip select signals exist for 8bit/ 16bit SPI BUS
*8: Half-duplex communication method
*9: Includes 256KByte test area
*10: Includes 1KByte test area



These low power microcontrollers are ideal for compact, battery-driven systems without an LCD. The units integrate program memory (32KB-64KB), RAM (1KB-4KB), 3 types of serial communication ports (I2C, SSIO, UART), a battery voltage detection circuit, 2 types of A/D converters (24bit RC, 12bit successive approximation), timer, PWM,general-purpose port , and LED driver terminal into a single chip.


Part No.

Operating condition

ROM/RAM

Function/Feature

Package

In
chip

Operating
votage
(V)

Operating*1
frequency

Current*3
con
-sump
-tion
(Typ.
@HALT)

Operating
temper
-ature
(°C)

ROM
capacity
(Byte)

RAM
capacity
(Byte)

WDT

ADC
(Method)

Serial port

I2C

SSIO*7

UART*8

  • ML610482

  • ML610482P

1.1
to
3.6

4.096MHz
500kHz
32.768kHz

0.5μA

–20 to +70
/–40 to +85

Mask 64K*10

4K

1

2
(RC oscillation)

1*5

1

1

TQFP
48

OK

  • ML610Q482

  • ML610Q482P



1.1
to
3.6

4.096MHz
500kHz
32.768kHz

0.5μA

–20 to +70
/–40 to +85

Flash 64K*10

4K

1

2
(RC oscillation)

1*5

1

1

TQFP
48

OK

NEW

  • ML610Q484

  • ML610Q484P



1.25
to
3.6

4MHz
500kHz
32.768kHz

6.0μA

–20 to +70
/–40 to +85

Flash 16K*10

1K

1

1
(RC oscillation)

-

1

1

WQFN
28

OK

under development

  • ML610Q486
    ML610Q486P



1.6
to
3.6

500kHz

15μA

–20 to +70
/–40 to +85

Flash 32K*10

1K

1

4
(Succesive)

1*6

1

1

TQFP
48

OK

*1: 4MHz supports internal PLL, ceramic, crystal, or RC oscillation; 2MHz, 1MHz, or 500kHz supports RC oscillation; 32.768kHz supports crystal oscillation; 32kHz supports RC oscillation
*3: Current consumption during Suspend (HALT) mode at low-speed 32kHz oscillation
*5: Master function only, supports both Fast Mode (400kbps) and Standard Mode (100kbps)
*6: Master function only, supports Standard Mode (50bps)
*7: No compatible chip select signals exist for 8bit/ 16bit SPI BUS
*8: Half-duplex communication method
*10: Includes 256KByte test area
